Semi-Electric Self-Loading Stacker

The Vango 1000 is a modern self-loading semi-electric stacker with a 1000kg capacity and a lift height of 1.3 metres.

Capacity: 1000kg
Capacity: 400mm
Max Lift Height: 1300mm
Maximum Fork Height (Mast Closed): 1666mm
Width of Fork: 193mm
Width across forks: 563mm
Fork Length: 1150mm
Overall Length: 1544mm

This is a versatile model because its unique design allows it to be loaded or unloaded into the back of a vehicle, with no external lifting equipment required.

Some of the features of this unit include:

Self-loading: Can be loaded into the back of a suitable vehicle and can also be unloaded, with no external lifting equipment required (We recommend watching the video below).
Fork size: 563x1150mm
Capacity: 1000kg
Power: 12v45Ah Battery
Motor: 1.6kW DC
Minimum turning Radius: 1100mm
Lift speed: 82mm/s
Lowering speed: 66mm/s
Rear body width: 835mm
